Physical Connectivity
Trace the complete path, not just two endpoints.
Model exact Ports, compatible media, Splitters, breakouts, Patch Panels, labels and every intermediate physical dependency.
Interactive connection model
Switch the medium. Keep the physical truth.
This illustrative demo uses the same connection vocabulary as Tenqora. Choose a method to see how endpoints, intermediate components and compatibility context change.
xe-0/1/2SFP+ · 10GbE · Front
SFP+Generic SFP-10G-LR
RT
xe-0/1/5SFP+ · 10GbE · Front
SFP+Generic SFP-10G-LR
R
One validated source TX feeds two receiver branches through a passive 1×2 Splitter.
Illustrative topology · compatibility remains configuration-specificCompatibility engine
Prevent invalid physical combinations before installation.
Optical paths
Fiber mode, application, wavelength, connector, polish, loss and transceiver identity remain explicit.
Splitter routes
Named input and output Ports, branch identity and validated TX-to-RX behavior are retained.
Captive assemblies
DAC and AOC are one serialized two-ended cable, never two independent transceivers.
Patch Panels
Copper and optical panels preserve front/back Port identity and compatible media.
Special protocols
Serial, KVM, InfiniBand and Fibre Channel stay within their physical and protocol rules.
Operational output
Connected-only or complete reports, labels and exact route evidence are ready for field work.
One path record
From intent to installation and impact.
- Exact Equipment, module and Port at both ends
- Inventory identity for installed cable, optic or component
- Planned, connected, verified and historical states
- Reverse-side route that mirrors the same physical truth
- Safe delete, edit and impact-aware work execution
